©Copyright Agrispread September 2014 29
830 Belt Spreader
Adjusting Height of Hitch
It is possible to raise or lower the hitch as shown in figure below.
To lower the hitch
1. Remove bolt and nuts using a size 30 spanner.
2. If the hitch requires to be lowered, lower the swivel hitch one hole.
3. Realigned holes and replace bolts, nuts and washers.
4. Ensure nuts and bolts are tightened sufficiently.
To raise the hitch
1. Remove bolt and nuts using a size 30 spanner.
2. If the hitch requires to be raised, raise the swivel hitch one hole.
3. Realigned holes and replace bolts, nuts and washers.
4. Ensure nuts and bolts are tightened sufficiently.
1
1
Hitch types may vary however procedure for adjusting the hitch height remains the same
