Agri-Spread AS35 - Recommended Spinner Speeds For Spreading

38 ©Copyright Agrispread September 2014
830 Belt Spreader
Recommended Spinner Speeds For Spreading
Spread Width With Standard Spinner Disks (See Figure A)
Material 12 M Deflector
/Cross Bar
Position
18 M Deflector
/Cross Bar
Position
24M Deflector
/Cross Bar
Position
Lime 450-650
RPM
See Figure 1
/ Figure 2
_________ _________ _________ _________
Fertiliser 600-650
RPM
See Figure 3 750-820 RPM See Figure 4 800-950 RPM See Figure 4
Sand 600-650
RPM
See Figure 1
/ Figure 2
_________ _________ _________ _________
Table 1 : Recommended Spinner Speeds For Spreading 2
Figure A: Standard Spinner Disk
2
Recommended Spinner Speeds Are To Be Used As A General
Guideline For Initial Set-Up. Spreader Must Be Tray Tested For
Final Adjustment.
