©Copyright Agrispread September 2014 7
830 Belt Spreader
Gear Box Parts
Gear Selection Details
Gear Change:
To change gear, remove “R” Clip from gear selector. Complete gear change by moving gear
selector to gear required. (See Figure 3 below)
When selecting gear it is necessary to rotate the Jockey wheel manually in order to select
required gear.
After selecting required gear, reinsert “R” Clip as shown above.
