830 Belt Spreader
Figure 5 (Wide Spread Disks)
Cross Bar
Folded
Up &
Center V
Inserted
Intial Tray Test Setup Start Up Position
Contact Plate B at 3
rd
Notch
Contact Plate A Meeting
Plate B & Parallel With
Ground
