Power Hoe 1000 7
Unpacking and Assembly
Open the box top.
Mount handlebar
Remove the clamping lever (4) to-
gether with the washer (3) from the
machine.
l
Attach the steering handle (1) to
its bearing (2), using the clamping
lever (4) and washer (3) (ensure that
cables and electric lines are not
twisted or jammed).
l
Adjust the handlebars to working
height and lock the gears into mesh.
l
Tighten the clamping lever.
l
Connect the electric line (for safety
circuit lever) to the socket (5 + 6).
l
Inspect again whether all Bowden
cables are routed properly and are not
twisted or jammed to avoid clutch
problems.
l
Remove the machine from the box
or cut it open in 4 corners to fold down
the sides.
Attach all hoeing tools and guards
Attach depth bar
Attach the rear support wheel
Carry out the start-up procedure
19
20
22
20
