5.2) Quick release buckle retention system
With the quick release buckle retention system, the strap
must be adjusted before being fastened.
Following the indications in the gure below, adjust the leng-
th of the strap, lengthening or shortening the portion of tape
that passes through the metal ring (1) until the helmet fits
snugly when the strap is fastened.
In order to fasten the helmet, insert the buckle in the retention
mechanism (2) until you hear it click (3).
Make sure the helmet fits snugly (also see the paragraph
entitled “Choosing the right helmet” in the “Safety Warning”
booklet).
To remove the helmet, use
the red button (4) to open the
retention mechanism and
then open the buckle (5) as
shown in the gure below.
