EN
7.1 REMOVING/FITTING
CHEEK PADS
Prerequisite: in a seated position, place the helmet
upside-down on your knees.
To remove the cheek pads, hold them in front near
the chin guard and pull them in the direction of the
arrow to free them from the press studs
1
.
Slide the plastic flap out of its position and remove
the cheek pads
2
.
To put the cushions back in place, insert the plastic
strip in its rear slots
3
and in the relative pins on
the side of the cover
4
.
To refit the cheek pads, slide them into the helmet
and fasten them into place with the press studs
5
.
Make sure that the cheek pads are properly
fastened to the helmet.
3
4 5
1
2
