2.2 Fuses (4-13/17)
1 Traction drive 10,0 A
2 Turn indicator 7,5 A
3 Hydraulic 15,0 A
4 Heater 20,0 A
5 Rear window heater 20,0 A
6 High beams 15,0 A
7 Dimmed headlights 15,0 A
8 Tail light, left,
parking light, left 5,0 A
9 Tail light, right,
parking light, right 5,0 A
10 Hazard flasher 15,0 A
11 Window wiper/washer 20,0 A
12 Motor stopper 5,0 A
13 Working lights,
brake light 30,0 A
14 Warning beacon (opt.),
signal horn, plug socket,
interior lighting 30,0 A
opt. = optional equipment
View on the fuse box:
2.2 Fuses (4-13/17)
1 Traction drive 10,0 A
2 Turn indicator 7,5 A
3 Hydraulic 15,0 A
4 Heater 20,0 A
5 Rear window heater 20,0 A
6 High beams 15,0 A
7 Dimmed headlights 15,0 A
8 Tail light, left,
parking light, left 5,0 A
9 Tail light, right,
parking light, right 5,0 A
10 Hazard flasher 15,0 A
11 Window wiper/washer 20,0 A
12 Motor stopper 5,0 A
13 Working lights,
brake light 30,0 A
14 Warning beacon (opt.),
signal horn, plug socket,
interior lighting 30,0 A
opt. = optional equipment
View on the fuse box:
