ahlmann AL 70e - Hydraulic System; Fuel Supply System; Heating and Ventilation System; Return-Flow Suction Filter

3-6 K65E/K75D/K95D/K95i 3-6 K65E/K75D/K95D/K95i
o
3.2.11 Hydraulic system
- Contents 100 l
- Hydraulic oil reservoir 70 l
- Flow rate 61 l/min
- Max. operating pressure 230 bar
- 2 lifting cylinders Ø 80/50 mm
- 1 tilt cylinder Ø 100/60 mm
- 1 steering cylinder Ø 85/35 mm
- Times acc. to DIN ISO 7131
- Lift (with payload) 5.8 s
- Lower (without payload) 3.8 s
- Dump 90° 1.2 s
- Tilt 45° 1.0 s
3.2.12 Fuel supply system
- Contents
fuel tank 70 l
3.2.13 Heating and ventilation system
- Oil heater COBO
- Type 2/9008/COMB-10/A45
- Heat output,
3-stage Q
80
max. 10.5 kW at V
oil
30 l/min
- Fan power,
3-stage max. 785 m³/h
3.2.14 Return-flow suction filter
- Filter mesh 15 µm abs.
- By-pass activation pressure p = 2.5 bar
- Pretension 0.5 bar
3.2.15 Electrical contamination indicator
- Activation pressure p = 2 bar
3.2.16 Oil cooler with temperature-controlled fan
- Power max. 15 kW
- Flow rate 23 l/min
