3.5 Attachments AL 85t
NOTE
- The technical data refer to tires of size 365/80 R 20.
3.5.1 Buckets
3.5 Attachments AL 85t
NOTE
- The technical data refer to tires of size 365/80 R 20.
3.5.1 Buckets
Bucket type Standard bucket
Bucket volume m³ 0,8
Bucket width mm 1850
Dead weight kg 283
Loads according to DIN 24094
*
Bulk density t/m³ 2,0
Rated dump load
- frontal kg 3670
- swiveled kg 3230
Rated payload
- frontal kg 1835
- swiveled kg 1615
Operating weight without attachment * kg 4990
* with water in the rear axle wheels
Bucket type Standard bucket
Bucket volume m³ 0,8
Bucket width mm 1850
Dead weight kg 283
Loads according to DIN 24094
*
Bulk density t/m³ 2,0
Rated dump load
- frontal kg 3670
- swiveled kg 3230
Rated payload
- frontal kg 1835
- swiveled kg 1615
Operating weight without attachment * kg 4990
* with water in the rear axle wheels
