3.6 Attachments AL 100t
NOTE
- The technical data refer to tires of size 14.5 - 20.
3.6.1 Buckets
3.6 Attachments AL 100t
NOTE
- The technical data refer to tires of size 14.5 - 20.
3.6.1 Buckets
Bucket type Standard bucket
Bucket volume m³ 0,9
Bucket width mm 1950
Dead weight kg 306
Loads according to DIN 24094
*
Bulk density t/m³ 2,0
Rated dump load
- frontal kg 4170
- swiveled kg 3660
Rated payload
- frontal kg 2085
- swiveled kg 1830
Operating weight without attachment * kg 5320
* with water in the rear axle wheels
Bucket type Standard bucket
Bucket volume m³ 0,9
Bucket width mm 1950
Dead weight kg 306
Loads according to DIN 24094
*
Bulk density t/m³ 2,0
Rated dump load
- frontal kg 4170
- swiveled kg 3660
Rated payload
- frontal kg 2085
- swiveled kg 1830
Operating weight without attachment * kg 5320
* with water in the rear axle wheels
