2 Product description
General information
AHT products comply with EU Directive 1907/2006
(REACH) for the registration, evaluation, approval
and limitation of chemical materials. In the product
design, the manufacturer has considered the
environmental and disposal-friendliness of the
device, in particular, for the refrigerant propane (R-
290) and the propellant pentane (for the insulating
foam). Propane does not have any ozone depletion
potential (ODP) and only a very low greenhouse
potential (GWP) of 3. The refrigerant R-404A is
recorded in the Kyoto Protocol. It does not have any
ozone depletion potential (ODP) and has a
greenhouse potential (GWP) of 3922.
Technical data
Important technical data can be found on the power
rating plate (see → Chapter 2.2.1).
External dimensions
Total weight of the
device
See → Device models
overview.
Airborne noise
emissions
Emission sound pressure
level
< 70 dB(A)
Maximum load on
storage racks
See → following table and
Chapter 9.1
Storage rack
Device type
Maximum
load [kg]
Display shelf (shelf) or
floor plate / floor shelf
AC-S/AC-M
AC-W
AC-XLS
AC-XL
35
40
50
85
M-package temperature class according to EN ISO
23953-2
M2
Technical interfaces:
Voltage supply (device-
specific, observe the
specifications on the power
rating plate, see → 2.2.1)
with Connector types
(Device connector) Other
country-specific versions
available.
All device types
220-240 V 50 Hz
CEE plug type 7
Device type: AC-S, AC-M,
AC-W, AC-XLS
110-120 V 60 Hz
NEMA 5-15P
NEMA 5-20P (AC-M)
Device type:
AC-XL, AC-XLS
208-240 V 60 Hz
NEMA L6-15P
Minimum requirements
for the connecting
cable:
Minimum cross-section
220-240 V 50 Hz
1.5 mm²
110-120 V 60 Hz and
208-240 V 60 Hz
2.5 mm² (14AWG)
Electrical protection (see → Chapter 7.2):
Fuses
Rated current
[A]
Triggering
characteri
stics
Type
Fault
curren
t [mA]
for
220-
240V
for
110-
120V
for
208-
240V
LS
(CB)
16
15
20*
15
C
(time-lag)
_
_
FI
(RCCB/
GFCI)
≥ 40
≥ 40
≥ 40
_
surge current-
resistant short-
circuit delayed
(e.g. G/AP-R)
30
FI-LS
(RCBO)
16
15
20*
15
C
(time-lag)
surge current-
resistant short-
circuit delayed
(e.g. G/AP-R)
30
*Only for device type: AC-M
If you need more information, please contact the
maintenance services (see → Chapter 10.4).
Power rating plate and serial
number
When handling the device, the information on the
“power rating plate” must be observed. This is found
on a sticker on the rear side of the device and
contains important technical data about
Device name and device type,
Serial number,
Climate class* (see → Chapter 1.3),
Rated voltage and rated frequency,
Rated current and rated consumption,
Refrigerant and amount used,
Net content,
Date of manufacture,
Test mark,
and other technical data.
*Examples of climate classes:
Climate class
according to ISO
23953-2
Ambient
temperature [°C]
Relative
humidity [%]
3
25
60
Classification
according to NSF 7
ambient temperature
typically does not exceed
Type I display
refrigerator (Type I)
75°F (24°C)
The unit is designed for air-conditioned stores, where
relative humidity typically is maintained at or below 55%.
Intended use
The device is suitable for storage of packaged
cooled food products.
For additional information, see → Chapter 1.3
3 Layout and function
The device is a compact device ready to plug in.
All individual devices are delivered ready for
operation and have their own control unit.
The devices are pre-programmed at the factory.
Each device contains one or more hermetically
closed refrigerant circuits, the components of which
