AIC Auriga - 1.2 Specifications

2
Chapter 1. Product FeaturesAuriga User Manual
1.2 Specifications
System
Processor
Support
Single AMD EPYC™ 7000-series
CPU TDP
180W
Socket Type
Socket SP3
System
Memory
• DDR4 2666MHz
• Total 8 memory slots ; 8 channels
• Supports up to 1TB
Expansion
Slots
• 4 x Slimline x12 + 7 x Slimline x4
• 2 x PCI Express Gen4/Gen3 x16 slots
(Gen4 supported by Rome CPU)
• 1 x OCP Mezzanine V2.0 support
PCI Express Gen4/Gen3 x16
(Gen4 supported by Rome CPU)
Total support 124 lanes of PCI Express
Gen4/Gen3
(Gen4 supported by Rome CPU)
System BIOS
BIOS Type
Insyde UEFI BIOS
BIOS
Features
On-board
Devices
SATA/NVMe
• 2 x SATA 6.0 Gb/s
• 2 x SATA 6.0 Gb/s by M.2 (M-key)
supports up to 22110
(optional - above 4 SATA ports can be
replaced with 2 x PCIe x1 M.2)
On-board
Devices
BMC
Aspeed AST2500 Advanced PCIe Graphics &
Remote Management Processor
• Baseboard Management Controller
• Intelligent Platform Interface 2.0 (IPMI 2.0)
• iKVM, Media Redirection, IPMI over LAN,
Serial over LAN
• HTML5
Graphics
Aspeed AST2500 Advanced PCIe Graphics &
Remote Management Processor
• PCIe VGA/2D Controller
• 1920x1200@60Hz 32bpp
Input/Output
SATA/NVMe
• 2 x SATA 6.0 Gb/s
• 2 x SATA 6.0 Gb/s by M.2 (M-key)
supports up to 22110
(optional - above 4 SATA ports can be
replaced with 2 x PCIe x1 M.2)
LAN
• 1 x GbE RJ45 dedicated to BMC management
USB
• 2 x USB 2.0/3.0 Type-A connectors on rear I/O
• 2 x USB 2.0/3.0 by onboard vertical type A
connectors
VGA
• 1 x external VGA port
• 1 x internal VGA pin-header
(share with external VGA port)
Serial Port
• 1 x external 3.5mm phone jack for COM port
• 1 x internal COM pin-header
Others
• 1 x TPM 2.0 onboard
• ACPI
• PXE
• IPMI KCS interface
• SMBIOS
• Serial console redirection
• SRIOV
• iSSCI
• TPM
• PCIe Hotplug
