AIC Auriga - 3�2 Content List

10
Chapter 3. Motherboard SettingsAuriga User Manual
3�2 Content List
Connector/Jumper/Header Location Connector/Jumper/Header Location
1a
1b
1c
1d
1f
1g
1h
PCIe Bus
JG0FR1, JG0FR2
JG1FR1, JG1FR2
JG2FL1, JG2FL2
JG3FL1, JG3FL2
24
Battery Socket (For
CR2032)
JBAT1
2a
2b
2c
2d
FAN connector
JFAN1, JFAN2,
JFAN3, JFAN4
25 Clear CMOS JCMOS1
3 HDT CONN JHDT1
26a
26b
External Thermal Sensor
JTHM1, JTHM2
4 PMBUS JPMBUS1 27 BMC Debug Port JBMC_DP1
5 Power Supply
JPWR1:12V &
5VSB. 6° per pin.
28 Internal VGA Port JVGA2
6a
6b
Internal USB2.0/3.0 JUSB2, JUSB3 29 External VGA port JVGA1
7 CPU Sockets JCPU0 30 External USB2.0/3.0 x2 JUSB1
8 DIMM Sockets
JDMA0, JDMB0,
JDMC0, JDMD0,
JDME0, JDMF0,
JDMG0, JDMH0
31 BMC Console Port JCONSOLE1
9a
9b
9c
PCIe Bus
JP1R1
JP1R2
JP1R3 (Reserve)
32a
32b
NGFF(M.2) CONN JNGFF1 , JNGFF2
10 Power VR I2C Header JPWR_I2C1 33 OCP connecter JOCP1
11a
11b
SATA DOM Power
Enable Jumper
JSATA1_PWR2,
JSATA2_PWR2
34 OCP connecter JOCP2
12a
12b
SATA-DOM Power
JSATA1_PWR1,
JSATA2_PWR1
35 CPLD Debug Port (NC) JTAG1
13a
13b
SATA HDD connector JSATA1, JSATA2 36 RACK Connection JRACK1
14 UART0/UART1 of SOC JUART0 37 SSI connector JSSI1
15
Switch for UART0/
UART1
J1 38
Chassis Open/Close
Intruder
JINTRUDER1
16 BMC Reset JBMC_RST1 39 BMC Buzzer JBUZZER1
17 BMC GPIO JBMC_GPIO1 40 Internal LAN Header JLAN2
18 LPC Debug Port JLPC1 41 IPMB JBMC_I2C1
19 Internal USB2.0
JUSB_INT1
(Output from
USB2.0 Hub)
42 BMC COM2 Header JCOM1
20
BMC rmware disable
jumper
JBMC_DIS1 43 Front Plane Controller JLCM1
21 Standard PCIe slot x16 JPCIE1 44 Standard PCIe slot x16 JPCIE2
22
BMC Firmware ROM
socket
JBMC_ROM1 45 RJ45 connector JLAN1
23
System BIOS ROM
socket
JSPI_BIOS1
46a
46b
BMC Console Port
Selection
J3, J4
