3�4�1 Rear Panel LED
Cable Link/Active Status:
LAN1 (Right, JLAN1 Pin-13,14)
Green
1. Cable Plug-In : Green
2. Cable Plug-Out : Off
Linking Speed:
LAN1 (Left, JLAN1 Pin-15,16)
Green,
Amber
1. 1Gbps : Green
2. 100Mbps : Amber
3. 10Mbps & No connect: Off
3�4�2 Internal LED
LED1
JSATA1 status LED
(U2005 ASM1061)
ON (Blinking) Indicates SATA is in use when LED is lit.
OFF Indicates SATA is un-used when LED is dark.
LED2
JSATA2 status LED
(U2008 ASM1061)
ON (Blinking) Indicates SATA is in use when LED is lit.
OFF Indicates SATA is un-used when LED is dark.
LED3
HEART BEAT
ON(Blinking) BMC activity is detected.
ON BMC is not active.
LED6
RSMRST LED
ON Resume Well Reset is ready.
OFF Resume Well Reset is not ready.
LED7
POWER GOOD LED
ON System power good is ready.
OFF System power good is not ready.
LED8
UID LED
ON (Blinking) UID activity is detected.
OFF UID activity is not detected.
3�4 System LED Indicator
