AIDA HD-100A - SPECIAL FUNCTIONS: HLM, DEFECT PIXEL, BINNING; HLM (Highlight Masking); Defect Pixel Correction; Binning

12
HLM : OFF, ON
HLM can be adjusted.
• AREA DISPLAY : ON, OFF
HLM AREA DISPLAY can be turned ON or OFF.
• SIZE/POSITION : SIZE, POSITION, RETURN
• Adjust BLC area window size.
• LEVEL : 0 ~ 20
Amount of masking area can be adjusted.
• BLACK MASK : OFF, ON
Masking area highlight can be turned ON or OFF.
• DEFAULT : Set HLM menu to default value.
BINNING : OFF, ON
Binning can be turned ON or OFF
DEFECT PIXEL : OFF, ON, ON (FIXED), STATIC
Defective Pixel Correction feature can be operated. It is turned ON by default and
will run both dynamic and static DPC function.
SPECIAL
BACKLIGHT - HLM
AREA ON
*AREA DISPLAY ON
SIZE/POSITIO N
LEVEL 3
BLACK MASK ON
DEFA ULT
RETURN
DEFECT PIXEL
*STATIC PROGRESS PRESS OK
SDPC UPDATE PRESS OK
SDPC CLEAR PRESS OK
RETURN
