Aikoh Engineering RZ Series User Manual

－15－ －16－
Precautionsforinstallationontheelectricteststand
※Forthesettingprocedure,seepage9.
※Tousethegageincombinationwithotherelectricteststand,confirmthestop
directionpriortomakingthissetting.Ifthesettingisincorrect,evenifanoverload
occurs,theelectricteststandwillnotstop,breakingtheforcesensor.
※Forconnection,usetheoptionalcableRZ-OP-1orRZ-OP-2.
MODEL-1308U
Capacity ／1000N
Thegagemounting
partismovedupand
downelectrically.The
powersupplyisamulti
powersupplyof100V
to240V.
※Thedigitalforcegageisnot
includedwitheithermodel.
MODEL-2257
Capacity ／500N
Thismodeliselectrical
andwhentheincluded
baseplateisexchanged,
itcanbeusedeitheras
theverticaltypeorthe
horizontaltype.
Thepowersupplyisa
multipowersupplyof
100Vto240V.
（Overloadoutputdirectionchange）
Ifaforceexceedingtheratedcapacityisappliedtothemeasuringshaft,the
forcesensormaybebrokenandthegagemayfail.
WhenthegageisinstalledonAikohselectricteststand,anoverload
signalcanbeoutputfromthe26-pinI/Oconnectortotheelectricteststand
tostopthestand.Forthispurpose,itisnecessarytomakesetting
accordingtotheactiondirectionoftheelectricteststandandthedirection
ofaforcetobeapplied.
allowsselectionofeither or ForacombinationofAikohʼs
electricteststandModel1308andModel2257,select
Vertical/horizontalcombinedtype
Changingthescreendisplaydirection
（Screendisplaydirectionchange）
※Forthesettingprocedure,seepage9.
Thedisplayofthemeasuredvalueandunitcanbereversed.Usethis
functionwhenmountingthegageonateststand.
Thecontentsofsettingandthedisplaydirectionareasfollows.
Directionofthedisplaywhenthe
measuringshaftfacesupward.
Directionofthedisplaywhenthe
measuringshaftfacesdownward.
（UP）Upwardselected （DOWN）
Downwardselected
N
N
