Aikoh Engineering RZ Series User Manual

－17－ －18－
Usinganalogoutputs
Minimizingbatteryconsumptionforefficientuse
（Analogoutputzeroadjustment）
※ Forthesettingprocedure,seepage9.
Ananalogvoltageisoutputconstantlyfromthe26-pinconnectorprovided
atthebottomofthebody.(Approx.±2Vattheratedcapacity)
Theoutputpinnumbersareasfollows:
Thisgagecanrunforlonghoursafterithasbeenchargedfullyonce.Ifthe
powerisnotturnedoffbyamistakeornooperationisperformedforabout5
minutescontinuously,theautopowerofffunctionoperatestoturnoffthe
powerautomatically.ThisfunctionhasbeensettoONinthefactory,butifyour
environmentofusedoesnotpermitthepowertobeturnedoff,setthistoOFF.
Analogoutputvoltage ±2V/F.S.（Ratedcapacity）
Ratedcapacity No.19・・・AnalogOut（±2V/F.S.）
NO.20・・・AnalogGND(A.GND)
※Foroutputtingavoltage,usetheoptionalcableRZ-OP-2.
（Autopowerofffunctionenable/
disablesetting）
Theanalogvoltageisoutputinproportiontotheactualforcebeingappliedto
thesensor,regardlessoftheindicatedvalue.
Accordingly,avoltageproportionaltotheactualloadbytheorientationofthe
measuringshaftandthemassofthefixtureisoutput.Thisisnoteliminated
whentheindicationisresettozero,butbyadjustmentdescribedhere,the
outputvoltagewhenzeroresettingisperformedcanbebroughtclosetozero.
※Forsetting,connecttheoptionalcableRZ-OP-2tothegageandconnecta
digitalvoltmetertothesignallinecorrespondingtotheanalogoutputpinNo.
Then,selectthisitembythesettingprocedurepresentedonpage9.Using
the keyand key,changethefigureforwardorbackwardtomakethe
voltageindicatedonthedigitalvoltmetercloseto0mV.
Finally,pressthe keytostorethesetvalue.
ENT
（ON）Thepoweristurnedoff
whenthenonusecondition
continuesforapprox.5minutes.
（OFF）Thepowerisnotturned
offautomatically.
Automaticzeroresetting
Usingtheexternalzeroresettingfunction
（Autozeroresetfunctionenable/disablesetting）
※Forthesettingprocedure,seepage9.
WiththissettingatON,whentheindicatedvalueiswithintwodigits,itis
possibletoautomaticallyapplyautomaticzeroresettingeveryabout2
seconds.
ThisfunctionhasbeensettoOFFinthefactory.
（ON）SettingON
（OFF）SettingOFF
Inadditiontothe keyprovidedonthegage,itispossibletoresettheforce
valuetozerobyinputtinganexternalzeroresetsignaltothe26-pinconnector
atthebottomofthegage.
PinNo.…Pin15（ZeroIn）−Pin17(GND)
ByshortcircuitingPin15andPin17shownabove,itispossibletoresetthe
forcevaluetozerofromexternalequipment.
※No-voltagecontactinput
Shortcircuiting15‒17lessthan1sec.…Onlythepeakforcevalueisreset.
Shortcircuiting15‒17longerthan1sec.…Thepeakforcevalueandtrack
valuearereset.
ZERO
