Checkingtheunits
SelectaunitofmeasurementfromN,Kgfandlb.
（3-unitsystem）
Eachtimethe keyispressed,theunitisshown
belowtheforcevalueintheorderofKgf,lbandN.
※ThisfunctioncannotbeusedwhenNhasbeen
set.
④
⑤
Forcezero
Pressingthe keywithoutapplyingaforceresets
theindicatedvaluetozero.
Continuemeasurement.
ZERO
Eachtimethe keyispressed,thenumberof
piecesofdatainthememoryisshownintheforce
displayforabout1second,Mlightsupinthe
upperleftcornerofthescreenandthepresent
numberofpiecesofdatainthememoryisshownin
thelowerright.Whendataisstoredinthememory,
theindicatedvaluewillberesettozeroandthe
gagewillbecomereadyforthenextmeasurement.
MEMO
Storingandprintingdata
Ifthereisdatathatneedstobestoredduring
measurement,pressthe key.Thenthatdatawill
bestoredinthememory.
Whenthe keyispressed,thedatawillbe
printed.
MEMO
PRT
①
①
Press②whilepressing①.
②
②
Callinganddeletingdata
Onlythedatathatwasstoredlastinthememory
canbecalledanddeleted.
Whenthe keyispressedwhilepressingthe 
key,thedatastoredlastwillbecalled.Then
pressingthe keydeletesthecalleddataandthe
gagewillreturntothenormaloperation.Ifthe 
keyispressedwithoutpressingthe key,the
calleddatawillbereturnedtothememory.
FUNC
ZERO
ZERO
MEMO
Printingdatainthememory
Theprintersthatareconnectabletothisgageare
thefollowingtwotypes:
①MITUTOYO-madeDP-1VR(MitutoyoDigimatic
outputconnection)
※
Forconnection,usetheoptionalcableRZ-OP-3.
②SANEIELECTRIC-madeBL2-58SNWJC(RS232C
connection)
※
Forconnection,usetheoptionalcableRZ-OP-4.
Whenthegagehasbeenconnectedtoaprinter,
printdatainthememorycollectively.
Whenthe keyispressedwhilepressingthe 
key,thedatainthememorywillbeprintedoneafter
another.
FUNC
PRT
