-33- -34-
OptionalCable
SaneiElectricLineThermalPrinterCable[RZ-OP-4]
Signalcable(black)UL,AWM(withshield)
・OD4.5-5.0mm ・Corewire5pcs ・CorewireOD1.0-1.5 ・AWG24(0.2㎟)
HiroseElectricRound10-pinconnector
HR212-10P-10PC(71),(112-4052-4-71)
9-pinD-subconnector(female)
pinNo
1
2
3
4
5
6
7
8
9
10
HR212-10P-10PC(71)
RD
RTS
TD
CTS
D.GND
−−−−−−−−−−
−−−−−−−−−−
−−−−−−−−−−
−−−−−−−−−−
−−−−−−−−−−
WireColor
White
Red
Black
Orange
Brown
−−
−−
−−
−−
−−
pinNo
1
2
3
4
5
6
7
8
9
D-sub9P(Female)
−−−−−−−−−−
RD
TD
−−−−−−−−−−
D.GND
−−−−−−−−−−
RTS
CTS
−−−−−−−−−−
2000mm
RZ-20
200N
(20Kgf)
0.1-200.0N
(10gf-20.00Kgf)
RZ-2
20N
(2Kgf)
0.01-20.00N
(1gf-2.000Kgf)
RZ-5
50N
(5Kgf)
0.01-50.00N
(1gf-5.000Kgf)
RZ-50
500N
(50Kgf)
0.1-500.0N
(10gf-50.00Kgf)
RZ-100
1000N
(100Kgf)
0.1-1000.0N
(10gf-100.00Kgf)
RZ-10
100N
(10Kgf)
0.01-100.00N
(1gf-10.000Kgf)
ListofModels
Standardspecifications
RZ-1
10N
(1Kgf)
0.001-10.000N
(0.1gf-1.0000Kgf)
0.001N(0.1gf)
0.01N(1gf) 0.1N(10gf)
・Unitofmeasurement…………Nor(gf)Kgf/N/lbselection
・Accuracy…………………………Within±0.2%oftheratedcapacity
・Allowableoverload ……………120%oftheratedcapacity(Overloadwarningatabout110%)
・Measurementsystem…………Trackmode/Peakholdmode/Compression/tensionpeakhold
modeselection
・Indicationupdatecycle………1time/sec,2times/sec,5times/sec,10times/sec,
20times/secselection
・Samplingcycle …………………1ms,5ms,16ms,50ms,125msand250msselection
・Workingtemperaturerange…0to+40℃
Guaranteedtemperaturerange
…+5to+40℃
Continuousworkinghours……30hoursafterfullcharge
・Powersupply ……………………Dedicatednickel-metalhydrideAAAbatteryx3,dedicatedAC
adapter:Model780(5VDC/1000mA)
DedicatedUSBcable:ModelRZ-USB
Externaldimensions……………W68xD40xH232mm
・Mass ………………………………Approx.375g
Ratedcapacity
(R.C.)
Indicationrange
Model
Min.indication
resolution
Outsidedimensions
