2.2 Connector Assignment
2.2.1 I/O Connector X400 (DSUB25 male) Pin Assignment
Signal
Pin
Signal
CAN1_L
1
14
CAN1_H
CAN1_GND
2
15
-
-
3
16
CAN2_L
CAN2_H
4
17
CAN2_GND
-
5
18
-
CAN3_L
6
19
CAN3_H
CAN3_GND
7
20
-
-
8
21
CAN4_L
CAN4_H
9
22
CAN4_GND
-
10
23
-
-
11
24
IRIG-B_RX+
IRIG-B_RX-
12
25
IRIG-B_A+
IRIG-B_A-
13
Description of Signals at X400
Name
Description
-
This pin is not connected at the module.
CANx_L, CANx_H,
CANx_GND
CAN signals of CAN node x (x= 1, 2, 3, 4).
Physical layer according to ISO11898-2.
IRIG-B_RX+, IRIG-B_RX-,
IRIG-B input. Physical layer RS-422 compatible.
IRIG-B_A+, IRIG-B_A-,
IRIG-B analogue input.
