2.2.2 PMC Connectors
The module uses the PMC connectors Pn1, Pn2 and Pn4. Pn1 and Pn2 provide the PCI interface
and power supply connection. Pn1 and Pn2 are according to PMC specification. Pn4 is not used
at this module variant and the pins shall not be connected.
