AMC825 Hardware Manual 9
GmbH
3 TECHNICAL DATA
3.1 General Technical Data
Power supply voltage
Nominal voltage: 5 V/DC or 3.3 V/DC, Universal board
Current consumption (20 °C):
typical: 5 V : 56 mA
3,3V: 570 mA
Connector
P11 (Pn1):
P12 (Pn2):
P14 (Pn4):
X400:
(64-pin PMC connector) - PCI bus
(64-pin PMC connector) - PCI bus
(64-pin PMC connector) - IRIG-B (TTL level only)
(DSUB25) - CAN, IRIG-B (physical layers available)
Temperature range
Standard:
0...50 °C ambient temperature
Extended:
-20...+75 °C (on request)
Conduction
Cooled:
Ask factory for availability.
Humidity
max. 90%, non-condensing
Dimensions
74.0 mm x 149.0 mm (single PMC size)
Weight
AMC825: 81 g
3.2 PCI Bus
Host bus
PCI-Bus according to PCI Local Bus Specification 2.2
PMC specification
IEEE Standard 1386.1-2001
PCI bus master capability
yes
PCI-data bus
32 bit
PCI bus clock rate
66 MHz / 3.3 V signal level
33 MHz /3.3 V signal level or 5 V signal level Universal board
Microprocessor
optional: 32-bit microprocessor in FPGA
Memory
Block RAM: 72 KB
optional DRAM: 64 MB
Interrupt
interrupt signal INT A
Connectors
P11 (Pn1), P12 (Pn2), P14 (Pn4)
according to IEEE Standard P1386.1-2001
