AIMS Power SCC-100A MPPT User Manual

23
Data Sheet
Model SCC20A MPPT SCC30A MPPT SCC40AMPPT SCC60AMPPT SCC80AMPPT SCC100AMPPT
Solar System Voltage 12V/24V 12V/24V/36V/48V
Electrical
PV operating voltage
18~100Vdc@12V
34~100Vdc@24V
15~155Vdc@12V
34~155Vdc@24V
50~155Vdc@36V
60~155Vdc@48V
Max. PV open circuit voltage
100Vdc
155Vdc
Rated PV input
12V 400W
24V 800W
12V 500W
24V 1000W
36V 1500W
48V 2000W
12V 800W
24V 1700W
36V 2400W
48V 3400W
12V 1200W
24V 2400W
36V 3600W
48V 4800W
12V 1400W
24V 2800W
36V 4200W
48V 5600W
Max. charging current 20A 30A 40A 60A 80A 100A
Max. DC load current 30A 40A 60A
Self-Consumption
＜
2W
＜4W
Conversion Efficiency
97%
97%
97.5%
98%
98.5%
Protection
Overload, short circuit, high voltage ,high temperature protection
Battery charging
Battery Type Gel, Sealed ,AGM, Flooded, Lithium , User define
Charging Algorithm 3-stage: Bulk, Absorption, Float 4-stage: Bulk, Absorption, Float, Equalize
Bulk charge voltage Sealed:14.4V AGM Gel:14.2V Flooded:14.6V User define:10-15V
Float charge voltage Sealed/Gel/AMG:13.7V Flooded:13.6V User define :10-15V
Equalize charge voltage Sealed:14.6V AGM:14.8V Flooded:14.8V User define :10-15V
Low voltage reconnect
voltage
12.5V
Low voltage disconnect
voltage
10.5V (10.5~12.5V Adjustable)
Temperature compensation -5mV/℃ /2V with BTS(Optional)
Communication
Communication Port
---
RS485
Mechanical
Net weight 1.8KG 2KG 3.5KG 7KG 8,5kg 9KG
Gross weight 2.2KG 2.5KG 4KG 8KG 9.2KG 10KG
Dimensions 210*180*65 210*180*70 270*185*90 305*227*120 353*227*120 417*227*120
Packing box 250*240*140 250*240*140 320*260*155 470*353*215 525*353*215 561*353*215
Cooling Heatsink cooling
Enclosure IP43
Environment
Ambient Temperature
-25~60
℃
( Derating from 45
℃
)
Storage Temperature
-40
℃
~+80
℃
Humidity
100% non-condensing
Warranty
Two Years

AIMS Power SCC-100A MPPT Specifications

General

Brand	AIMS Power
Model	SCC-100A MPPT
Category	Inverter
Language	English
