Aiphone IS SERIES Quick Start Programming Guide

D. Click
Port number auto-setting
to assign the required ports to all stations that need to communicate
(see Figure 8.3).
E. Click
Temporarily stored
to save changes.
Figure 8.3: Port Number Auto-setting
6 | IS Series Hybrid System Programming Guide
Figure 8.1: IP Unit Registration - IP Unit Search Figure 8.2: Manual Entry
Step 8: IP Unit Registration - Host
A. Select IP unit registration from the menu on left.
B. Scroll down and click
IP unit search
in the lower right (see Figure 8.1).
C. Check the station(s) needing to be added to the Imported IP units list. Click
Add to the imported IP units list
to add them. Any units not appearing can be manually entered (see Figure 8.2).
A. Select Control units composition from the menu on left.
B. For each IS-IPC in this Site, select which control units will be used (see Figure 9.1).
Each IS-IPC can connect to a single IS-RCU or an IS-CCU with up to 2 IS-SCU and 4 IS-RCU control units.
C. Click
Temporarily stored
to save changes.
Figure 9.1: Control Units Composition
Step 9: Control Units Composition
