Figure 4.1: Select Language Figure 4.2: ID and Password
IMPORTANT:
By default, the IS-IP devices will be set to DHCP. If using DHCP, use the IS_IPSEARCH program found on the CD
to identify the IP address of the units. When not tied to a DHCP network, the units will have the default address
of 192.168.0.40. By default, all units have the same address, making it is important to hook up and program each
station one at a time.
A. Open a web browser and point the address bar to https://192.168.0.40. If using DHCP, enter the unit’s IP address
discovered with the IS_IPSEARCH program and hit [Enter].
Note: ensure that https (for security) is being used in the address bar.
B. A security certicate error message will appear. Click “Continue to this website.”
C. Choose preferred language (see Figure 4.1).
D. Log in to the unit using the default administrator ID “aiphone,” and default password “aiphone” (see Figure 4.2).
Step 4: Log in to IS-IP Device (IS-IPMV, IS-IPDV, IS-IPDVF)
4 | IS Series IP Direct System Programming Guide
A. Click the Setting button and click the Network tab.
B. Enter the Host’s IP address, the Connection password “aiphone” and choose the Network Interface Card from
the drop down list. Enter the license key provided in the CD case (limit one per PC).
C. Click Save .
Step 3: Install and Congure IS-SOFT Application (optional)
Figure 3.1: IS-SOFT Figure 3.2: Network Tab
IMPORTANT:
The software will attempt to make contact with the Host, but since the Host is not yet set up, the software will give
an error that it was unable to do so. Ignore this error and proceed to Step 4: Log in to IS-IP Device.
To Next Page
