Step 9: Advanced Station Settings
Figure 9.1: Advanced Station Settings
Figure 9.2: Advanced Settings - Video Door Station
Figure 9.3: Called Stations - Priority Figure 9.4: Called Stations
A. Select Advanced station settings from the menu on left.
B. The Advanced station settings table is populated based on the stations registered in Step 8 (see Figure 9.1).
C. To program a door, check box and click
Advanced settings
. A new window will open. If multiple units need to call
the same master station(s), check appropriate units and click
Advanced settings
.
D. Click
Called stations
(see Figure 9.2). A new window will open.
E. Select the Call priority level from the drop-down list (see Figure 9.3). Click
Reference
to open a new window to
select the masters to be called (see Figure 9.4). Once the masters have been selected, click
Close
.
7
Figure 9.5: Called Stations - Priority
F. The Advanced settings window will now display the master(s) that will be called (see Figure 9.5). If a master was
selected in error, check the box next to that master and click
Delete
to remove from the list.
G. Click
Close
to go back to the main Advanced station settings window.
H. Repeat Steps C through G for all video door stations.
I. Click
Temporarily stored
to save changes.
