Appendix
5
Specifications
Maintenance
• Clean the station gently with a soft, dry cloth. For difficult stains, dip a soft cloth in neutral detergent diluted with
water, wring it out well, and then clean unit.
• Use a soft, dry cloth (for use in wiping mirrors) when wiping the display.
Power PoE (IEEE802.3af Class 0 standard)
Power consumption For PoE, Stanby 5.3W, Max 11.6W (48 VDC)
For Card reader, Stanby 1.0W, Max 1.6W (12 VDC)
Communication Full duplex audio (depending on the destination station)
Display 7" TFT LCD display WVGA 800×480 (Approx. 1.15 million pixels)
Minimum illumination 5 lux
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Audio codec G.711 (u-law, A-law)
Video codec H.264/AVC (Main profile)
Protocol IPv4, IPv6, TCP, UDP, SIP RFC3261, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP,
FTP, DHCP, NTP, DNS, TLS
Encryption system TLS1.0, TLS1.1, TLS1.2
Packet transmission system Unicast and multicast
Number of units in address
book
Max. 9,998 units
(Number of stations that can be registered as a call destinations: IX/IXG stations: Max.9,998
stations + mobile applications: Max.9,999)
Number of Buildings Max. 99 buildings
Operating temperature -10 to +60°C (+14 to +140°F)
Materials Panel: Stainless steel (vertical alignment finished)
Main unit/case: Self-extinguishing resin
LCD display: Glass
Chassis: Die-cast aluminum
Color Front Panel: Silver
Main unit: Black
Dimensions 182 mm (7-3/16") [W] × 347 mm (13-11/16") [H] × 12.5 mm (1/2") [D] (exposed area)
Weight Approx. 2.4 kg (5.3 lbs)
Water/dust protection class IP65 (dust-proof/spray-resistant)
Impact protection class IK08
Important
• Do not use chemicals such as benzene or paint thinner. You may damage the surface of the device, or cause discoloration.
