INSTALLATION PARTS LIST
MAIN COMPONENTS
1) CORMORANT MkII Rooftop
Airconditioner
2) Roof Seal Gasket 2 Pce
3) Spigot
4) Extension Duct
5) Brace Assembly
6) Plenum
7) Plenum Filters x2
FITTINGS & FIXTURES
8) M8 Bolts x 4
9) Hold Down Bars x 4
10) Plenum Cover Screws x 4
11) Self Tapping Screws x 6
1
2
3
4
5
6
7
8 9 10 11
BEFORE INSTALLATION
Ensure that the installation instructions have been properly read and understood
Installation must conform nationally to wiring regulations and in particular AS3001 – 2008
DO NOT
attempt to modify or add components to the installation procedure
This equipment must only be serviced by a licensed refrigeration mechanic
If your installation varies from the method outlined please contact Aircommand for specialty advice
WARNING
Failure to properly install the unit or attempting to modify it in any way can be extremely hazardous and may result in property
damage and/or personal injury
Aircommand will not be held responsible for issues arising from incorrect or improper installation methods
