AIREDALE CSD 18 - Page 13

Ceiling Cassette
The SLIMLINE PERFORMER Ceilin
g
Cassette
–
Ductless Mini-S
p
lit
13
Technical Manual : AIR 8-105.
5
2 3/4
2 3/4
4 7/8
9 13/16
3
12 1/16
10
32 5/16
6 1/4
6 5/16
4 3/8
8 13/16
3 1/8
2 3/4
9 13/16
4 1/16
5 1/16
5 3/4
1 5/8
2 3/4
4 7/8
3 7/16
A
A
VIEW A-A
6
7
8
9
5
5
1
2
4
3
10
1. DX Suction Line
2. DX Liquid Line
3. HW Coil Inlet (Optional)
4. HW Coil Outlet (Optional)
5. Fresh AIr Intake (x3)
6. Branch Duct Opening (x4)
7. Pump Inspection Port
8. Condensate Drain
9. Control Panel
10. Mounting Bracket
31 3/8
1 7/828 9/16
12 9/16
28 11/16
32 3/8
4 3/4
11 5/8
2 5/8
37
37
11/16
Figure 13.1 – Dimensions – Medium Chassis
Model CSD/CSH 18 and CSD/CSH 24
