6
Step 14. Attach the blades to the blade
holders with the three blade screws and
flat washers provided for each blade.
Hand tighten securely.
Attach an assembled blade and blade
holder to the fan motor. Hand tighten
securely. Repete for each blade assembly.
BLADE & BLADE HOLDER INSTALLATION
Step 13. On the motor remove the five
shipping blocks by unscrewing the screws.
Set these screws aside for installing the
blades in Step 14.
Discard the five shipping blocks.
REMOVE SHIPPING BLOCKS
SHIPPING
BLOCKS
Note: Save these five screws, they
will be used in Step 14!
