7.14 Fastener Torques
Table 7-3
Recommended Assembly Torques
Item
Thread
Size
(mm)
Spanner
Size
(mm)
Torque
(Nm)
Torque
(lbf-ft)
Fusheng CA-51 Cylinder Head Bolt
M6
10
9
6.6
Fusheng VA-51 Cylinder Head Bolt
M8
13
22
16.2
Fusheng C/V/TA-65 Cylinder Head Bolt
M8
13
22
16.2
Fusheng HTA-65 Cylinder Head Bolt
M8
13
22
16.2
Fusheng V/TA-80 Cylinder Head Bolt
M10
16
44
32.5
Fusheng V/TA-100 Cylinder Head Bolt
M10
16
44
32.5
Fusheng TA-120 Cylinder Head Bolt
M12
18
76
56.1
Fusheng D-2/3/4 Cylinder Head Bolt
M8
13
22
16.2
Fusheng VW-50 Cylinder Head Bolt
M10
16
44
32.5
Fusheng TW-75 Cylinder Head Bolt
M12
18
76
56.1
Fusheng TW-100 Cylinder Head Bolt
M12
18
76
56.1
Fusheng B-1 Cylinder Head Bolt
M10
16
44
32.5
Fusheng B-2 Cylinder Head Bolt
M10
16
44
32.5
Fusheng B-3 Cylinder Head Bolt
M12
18
76
56.1
Fusheng Screw-In Oil Sight Glass
M27
27
10
7.4
Standard M5 Bolt Class 4.6
M5
8
2.1
1.5
Standard M6 Bolt Class 4.6
M6
10
3.5
2.6
Standard M8 Bolt Class 4.6
M8
13
8.5
6.3
Standard M10 Bolt Class 4.6
M10
16
17
12.5
Standard M12 Bolt Class 4.6
M12
18
30
22.1
Standard M5 Bolt Class 8.8
M5
8
5
3.7
Standard M6 Bolt Class 8.8
M6
10
9
6.6
Standard M8 Bolt Class 8.8
M8
13
22
16.2
Standard M10 Bolt Class 8.8
M10
16
44
32.5
Standard M12 Bolt Class 8.8
M12
18
77
56.8
Note: Apply only 80% of the listed torque when tightening onto an aluminium alloy component.
