AirSep
®
Corporation
AS-A—AS-P Series Instruction Manual 7-9
5) Cycle between two desired signals and make minor adjustments to adjusting
nut and knob as required to achieve exact set points.
6) After settings have been made, make permanent electrical connections.
If the adjustment of the switch has been made outside the line
of final application, the switch should be retested when
installed in the final line of application. Follow adjustment
instruction. Be sure switch can be test operated without
affecting the other equipment.
AS-D+ - AS-P Oxygen Generators
Refer to the Appendix D of this instruction manual for additional
information on the pressure switch.
1) Set the ON/OFF switch on the oxygen generator control panel to ON.
2) The pressure switch is mounted on the side of the control panel. Open the
front enclosure of the pressure switch.
Locate the two adjustment screws for the high pressure setting and the low
pressure setting respectively. Use a ¼-inch wrench or screwdriver to make
adjustments.
The adjustment screw normally requires less than a ¼ turn.
Turn either the high or low adjustment screw ¼-turn clockwise
to increase its pressure setting. Turn either screw
counterclockwise to decrease its pressure setting.
