Quick Start Guide
A&ESpecs•DeclarationofConformity
Architects and Engineers Specifications
The device shall provide two inputs that are selectable as
line or mic level with phantom power and four outputs (two
line level analog and two AES3 digital). All signal processing
(including input gains) shall be controllable via software.
Audio inputs and outputs shall be accessed via rear panel
XLRconnectors.
The Graphical User Interface (GUI) software shall be installer
programmable using the Windows
®
XPorVistaoperating
system. Computer connection and control shall be via
the devices’ rear panel Ethernet connector. The GUI shall
provide display and control of all signal processing and
configuration functions including, but not limited to: Input
andOutputGain•HighpassFiltering•LowpassFiltering
•De-essing•DownwardExpansion•Compression•
ParametricEqualization•SignalRouting•VoiceSymmetry
•Polarity.
The front panel shall include input and output level indication
aswellasindicatorsforPOWER,NETWORK,andREMOTE.
Additionally,afrontpanelLCDshalldisplaycertainsystem
parameters and may be used for preset recall via the front
panelUP,DOWNandMENUbuttons.
External control shall include preset selection and/or
comprehensive parameter adjustment, depending upon the
particular remote in use, and shall be via industry-standard
CAT5 cable with RJ45 connectors to the front or rear panel
REMOTEports.
All program memory shall be non-volatile and provide
program security should
power fail. 3rd party control systems may interface via
Ethernet using a published Control Protocol.
Audioconversionshallbe24-bit,48kHzwithcongurable
output sample rate. The dynamic range of the processor
shallnotbelowerthan113dBA-weighted.
The device shall have an IEC power input socket. The unit
shallmeetUL/CSAandCEsafetyrequirementsandcomply
with CE and FCC Part 15 emissions limits. The unit shall be
RoHS compliant. The chassis shall be constructed of cold
rolled steel and moulded plastic, and mount into a standard
19”1UEIArack.The device shall be an AirTools model
Voice Processor 2x, Engineered by Symetrix.
Declaration of Conformity
We, Symetrix Incorporated,6408216thSt.SW,
MountlakeTerrace,Washington,USA,declareunderour
sole responsibility that the product:
Voice Processor 2x
to which this declaration relates, is in conformity with the
following standards:
UL 60065, cUL 60065, IEC 60065,
EN 55103-1, EN 55103-2, FCC Part 15, RoHS
The technical construction file is maintained at:
Symetrix, Inc.
6408216thSt.SW
MountlakeTerrace,WA,98043USA
The authorized representative located within the European
Community is:
World Marketing Associates
P.O.Box100
St.Austell,Cornwall,PL266YU,U.K.
Dateofissue:February1,2009
Placeofissue:MountlakeTerrace,Washington,USA
Authorized signature:
DaneButcher,President,Symetrix Incorporated.
