5-4
PERFORMANCE DATA & PRESSURE CURVES
SM HDDHED 2-A.1 GB
5.1.5.2 Heating
1200
1450
1700
1950
2200
2450
2700
2950
3200
3450
3700
3950
-15 -10 -5 0 5 10 15
Outdoor WB Temperature [ °C]
Discharge Pressure [kPa]
15
20
25
Indoor DB
5.00
5.50
6.00
6.50
7.00
7.50
8.00
8.50
9.00
9.50
10.00
-15 -10 -5 0 5 10 15
Outdoor WB TemperatureC]
Input Current [A]
15
20
25
Indoor DB
