PRODUCT DATA SHEET
SM HDDHED 2-A.1 GB
2.2 HDD024 / HED024 // YDD 024
Model Indoor Unit
HDD/HED024
Model Outdoor Unit
YDD 024
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(4)
kW 6.45(1.40-7.00) 6.70(1.20-8.00)
Power input
(4)
kW 2.00(0.35-2.60) 1.85(0.35-2.70)
EER (Cooling) or COP(Heating)
(4)
W/W 3.22 3.62
Energy efficiency class A A
Power supply
V 220-240
Ph 1
Hz 50
Rated current A 9.0 8.3
Power factor 0.97 0.97
Prated (IDU+ODU) W 2700
Starting current A
Circuit breaker rating A 25
INDOOR
Fan type & quantity Crossflow x 1
Fan speeds
Cooling SH/H/M/L RPM 1350/1150/1000/850
Heating SH/H/M/L RPM 1350/1150/1000/900
Air flow (1) SH/H/M/L m3/hr 1000/800/700/550
External static pressure Min Pa 0
Sound power level
(2)
SH/H/M/L dB(A) 58/54/49/44
Sound pressure level
(3)
SH/H/M/L dB(A) 48/44/39/34
Moisture removal l/hr 4
Condenstate drain tube I.D mm 16
Dimensions WxHxD mm 1008x319x221
Net Weight kg 15
Package dimensions WxHxD mm 1073x395x313
Packaged weight kg 20
OUTDOOR
Refrigerant control EEV
Compressor type,model Sanyo Twin Rotary,C-6RZ146H1A
Fan type & quantity Propeller(direct) x 1
Fan speeds H RPM 690
Air flow H m3/hr 2900
Sound power level H dB(A) 66
Sound pressure level
(3)
H dB(A) 56
Dimensions WxHxD mm 955x700x396
Net Weight kg 55
Package dimensions WxHxD mm 1030x735x460
Packaged weight kg 60
Refrigerant type R410A
Scharg kg(5m) 1.7
Additional charge 20g/m(5m<L<20m)
Connections
between units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max. 20
Max.height difference m. Max. 5
Operation control type Remote control
