PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit DAF012
Model Outdoor Unit YIF012
Installation Method of Pipe ducted
Characteristics Units Cooling Heating
Btu/hr 11940 12280
Capacity (4)
kW 3.5 3.6
Power input (4) kW 1.2 1.1
EER (Cooling) or COP(Heating) (4) W/W 2.91 3.27
Energy efficiency class
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 5.4 4.9
Starting current A
Circuit breaker rating (IDU/ODU) A 6/13
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 1110/910/760
Air flow (1) H/M/L m3/hr 600/540/490
External static pressure Min-Max Pa 25(0~25)
Sound power level (2) H/M/L dB(A) 50/48/46
Sound pressure level(3) H/M/L dB(A) 40/38/36
Moisture removal l/hr 1.3
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 913x220x680
Weight kg 27
Package dimensions WxHxD mm 995x258x750
Packaged weight kg 32
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 900
Air flow H/L m3/hr 2800
Sound power level H/L dB(A) 66
Sound pressure level(3) H/L dB(A) 56
Dimensions WxHxD mm 848x540x320
Weight kg 32
Package dimensions WxHxD mm 878x590x360
Packaged weight kg 37
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 1.0/5
Additional charge per 1 meter g/m 30g/m
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max.20
OUTDOOR
Connections between units
Max.height difference m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
