PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit DAF018
Model Outdoor Unit YIF018
Installation Method of Pipe ducted
Characteristics Units Cooling Heating
Btu/hr 17060 19450
Capacity (4)
kW 5.0 5.7
Power input (4) kW 2.1 1.8
EER (Cooling) or COP(Heating) (4) W/W 2.38 3.16
Energy efficiency class
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 9.4 8.1
Starting current A
Circuit breaker rating (IDU/ODU) A 6/20
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 1000/920/780
Air flow (1) H/M/L m3/hr 840/750/680
External static pressure Min-Max Pa 25(0~25)
Sound power level (2) H/M/L dB(A) 52/50/48
Sound pressure level(3) H/M/L dB(A) 42/40/38
Moisture removal l/hr 1.9
Condenstate drain tube I.D mm 30
Dimensions WxHxD mm 1012x266x736
Weight kg 36
Package dimensions WxHxD mm 1120x308x795
Packaged weight kg 39
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 900
Air flow H/L m3/hr 2800
Sound power level H/L dB(A) 66
Sound pressure level(3) H/L dB(A) 56
Dimensions WxHxD mm 848x540x320
Weight kg 40
Package dimensions WxHxD mm 878x590x360
Packaged weight kg 45
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 1.5/5
Additional charge per 1 meter g/m 30g/m
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max.20
OUTDOOR
Connections between units
Max.height difference m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
