PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit DAF024
Model Outdoor Unit YIF024
Installation Method of Pipe ducted
Characteristics Units Cooling Heating
Btu/hr 23880 27300
Capacity (4)
kW 7.0 8.0
Power input (4) kW 2.66 2.51
EER (Cooling) or COP(Heating) (4) W/W 2.63 3.18
Energy efficiency class
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 11.9 11.3
Starting current A
Circuit breaker rating (IDU/ODU) A 6/25
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 1250/1220/1060
Air flow (1) H/M/L m3/hr 1400/1350/1220
External static pressure Min-Max Pa 25(0~80)
Sound power level (2) H/M/L dB(A) 54/52/50
Sound pressure level(3) H/M/L dB(A) 44/42/40
Moisture removal l/hr 2.4
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 1270x268x504
Weight kg 37
Package dimensions WxHxD mm 1345x268x594
Packaged weight kg 45
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 940
Air flow H/L m3/hr 3200
Sound power level H/L dB(A) 69
Sound pressure level(3) H/L dB(A) 59
Dimensions WxHxD mm 1018x700x412
Weight kg 59
Package dimensions WxHxD mm 1100x755x450
Packaged weight kg 64
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 2.2/5
Additional charge per 1 meter g/m 60g/m
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 5/8"(15.88)
Max.tubing length m. Max.30
OUTDOOR
Connections between units
Max.height m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
