Airwell DAF009 - 2.5 DAF030; YIF030 Product Data

PRODUCT DATASHEET
SM YIF 2-A.1 GB 2-5
2.5 DAF030 / YIF030
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit DAF030
Model Outdoor Unit YIF030
Installation Method of Pipe ducted
Characteristics Units Cooling Heating
Btu/h
r
28320 31050
Capacity (4)
kW 8.3 9.1
Power input (4) kW 3.00 3..00
EER (Cooling) or COP(Heating) (4) W/W 2.76 3.03
Energy efficiency class
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 13.4 13.4
Starting current A
Circuit breaker rating (IDU/ODU) A 6/30
Fan type & quantit
y
Centrifugal x 2
Fan speeds H/M/L RPM 1250/1220/1060
Air flow (1) H/M/L m3/h
r
1400/1320/1200
External static pressure Min-Max Pa 37(0~50)
Sound power level (2) H/M/L dB(A) 54/52/50
Sound pressure level(3) H/M/L dB(A) 44/42/40
Moisture removal l/h
r
2.5
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 1270x268x530
Weight kg 37
Package dimensions WxHxD mm 1345x283x594
Packaged weight kg 43
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, mode
Rotary
Fan type & quantit
y
Propeller(direct) x 1
Fan speeds H/L RPM 780
Air flow H/L m3/h
r
4200
Sound power level H/L dB(A) 69
Sound pressure level(3) H/L dB(A) 59
Dimensions WxHxD mm 980x790x427
Weight kg 70
Package dimensions WxHxD mm 1080x840x485
Packaged weight kg 75
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 3.6/5
Additional charge per 1 mete
r
g/m 60g/m
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 5/8"(15.88)
Max.tubing length m. Max.30
OUTDOOR
Connections between units
Max.height m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
