Airwell DAF009 - 2.9 DAF060; YIF060 Product Data

PRODUCT DATASHEET
SM YIF 2-A.1 GB 2-9
2.9 DAF060 / YIF060
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit DAF060
Model Outdoor Unit YIF060T
Installation Method of Pipe ducted
Characteristics Units Cooling Heating
Btu/hr 54590 63120
Capacity (4)
kW 16.0 18.5
Power input (4) kW 6.5 5.5
EER (Cooling) or COP(Heating) (4) W/W 2.46 3.36
Energy efficiency class
Power supply V/Ph/Hz 380-415V/3 Ph/50Hz
Rated current A
Starting current A
Circuit breaker rating (IDU/ODU) A 10/20
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 1320/1090/910
Air flow (1) H/M/L m3/hr 2500/-/-
External static pressure Min-Max Pa 37(0~150)
Sound power level (2) H/M/L dB(A) 63/60/58
Sound pressure level(3) H/M/L dB(A) 53/50/48
Moisture removal l/hr 4.7
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 1251x330x788
Weight kg 66
Package dimensions WxHxD mm 1334x330x882
Packaged weight kg 76
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Scroll
Fan type & quantity Propeller(direct) x 2
Fan speeds H/L RPM 940
Air flow H/L m3/hr 6000
Sound power level H/L dB(A) 74
Sound pressure level(3) H/L dB(A) 64
Dimensions WxHxD mm 950x1250x412
Weight kg 123
Package dimensions WxHxD mm 1110x1385x450
Packaged weight kg 134
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 5.0/5
Additional charge per 1 meter g/m 120g/m
Liquid line In.(mm) 1/2"(12.7)
Suction line In.(mm) 3/4"(19.05)
Max.tubing length m. Max.50
OUTDOOR
Connections between units
Max.height difference m. Max.30
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
