PRODUCT DATASHEET
2-10 SM YIF 2-A.1 GB
2.10 FAF012 / YIF012
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit FAF012
Model Outdoor Unit YIF012
Installation Method of Pipe Floor / Ceiling
Characteristics Units Cooling Heating
Btu/hr 11940 12280
Capacity (4)
kW 3.5 3.6
Power input (4) kW 1.17 1.10
EER (Cooling) or COP(Heating) (4) W/W 2.99 3.27
Energy efficiency class C C
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 5.24 4.93
Starting current A
Circuit breaker rating (IDU/ODU) A 6/16
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 790/670/550
Air flow (1) H/M/L m3/hr 790/670/550
External static pressure Min-Max Pa 0
Sound power level (2) H/M/L dB(A) 56/54/51
Sound pressure level(3) H/M/L dB(A) 46/44/41
Moisture removal l/hr 1.2
Condensate drain tube I.D mm 20
Dimensions WxHxD mm 836/238/695
Weight kg 27
Package dimensions WxHxD mm 935/295/805
Packaged weight kg 35.5
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 900
Air flow H/L m3/hr 2800
Sound power level H/L dB(A) 66
Sound pressure level(3) H/L dB(A) 56
Dimensions WxHxD mm 840x540x320
Weight kg 32
Package dimensions WxHxD mm 878x590x360
Packaged weight kg 37
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 1.0/5
Additional charge per 1 meter g/m 30g/m
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max.20
OUTDOOR
Connections between units
Max.height difference m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
