Airwell DAF009 - 2.11 FAF018; YIF018 Product Data

PRODUCT DATASHEET
SM YIF 2-A.1 GB 2-11
2.11 FAF018 / YIF018
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit FAF018
Model Outdoor Unit YIF018
Installation Method of Pipe Floor / Ceiling
Characteristics Units Cooling Heating
Btu/hr 17060 19450
Capacity (4)
kW 5.0 5.7
Power input (4) kW 2.03 2.07
EER (Cooling) or COP(Heating) (4) W/W E E
Energy efficiency class 1.10 1.23
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 1.10 1.23
Starting current A
Circuit breaker rating (IDU/ODU) A 6/20
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 1070/970/870
Air flow (1) H/M/L m3/hr 1070/970/700
External static pressure Min-Max Pa 0
Sound power level (2) H/M/L dB(A) 64/60/56
Sound pressure level(3) H/M/L dB(A) 54/50/46
Moisture removal l/hr 1.9
Condensate drain tube I.D mm 20
Dimensions WxHxD mm 836x238x695
Weight kg 27
Package dimensions WxHxD mm 935x295x805
Packaged weight kg 35.5
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 900
Air flow H/L m3/hr 2800
Sound power level H/L dB(A) 66
Sound pressure level(3) H/L dB(A) 56
Dimensions WxHxD mm 848x540x320
Weight kg 40
Package dimensions WxHxD mm 878x590x360
Packaged weight kg 45
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 1.5/5
Additional charge per 1 meter g/m 30g/m
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max.20
OUTDOOR
Connections between units
Max.height difference m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
