Airwell DAF009 - 2.12 FAF024; YIF024 Product Data

PRODUCT DATASHEET
2-12 SM YIF 2-A.1 GB
2.12 FAF024 / YIF024
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit FAF024
Model Outdoor Unit YIF024
Installation Method of Pipe Floor / Ceiling
Characteristics Units Cooling Heating
Btu/hr 23880 27300
Capacity (4)
kW 7.0 8.0
Power input (4) kW 2.61 2.59
EER (Cooling) or COP(Heating) (4) W/W 2.68 3.08
Energy efficiency class
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 11.7 11.6
Starting current A
Circuit breaker rating (IDU/ODU) A 6/25
Fan type & quantity Centrifugal x 2
Fan speeds H/M/L RPM 1360/1280/1240
Air flow (1) H/M/L m3/hr 1170/1080/1000
External static pressure Min-Max Pa 0
Sound power level (2) H/M/L dB(A) 60/58/56
Sound pressure level(3) H/M/L dB(A) 50/48/46
Moisture removal l/hr 2.35
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 1300X188X600
Weight kg 32
Package dimensions WxHxD mm 1414X248X724
Packaged weight kg 36
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 940
Air flow H/L m3/hr 3200
Sound power level H/L dB(A) 69
Sound pressure level(3) H/L dB(A) 59
Dimensions WxHxD mm 1018x700x412
Weight kg 59
Package dimensions WxHxD mm 1100x755x450
Packaged weight kg 64
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 2.2/5
Additional charge per 1 meter g/m 60g/m
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 5/8"(15.88)
Max.tubing length m. Max.30
OUTDOOR
Connections between units
Max.height difference m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
