Airwell DAF009 - 2.18 CAF018; YIF018 Product Data

PRODUCT DATASHEET
2-18 SM YIF 2-A.1 GB
2.18 CAF018 / YIF018
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit CAF018
Model Outdoor Unit YIF018
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Btu/hr 17060 19450
Capacity (4)
kW 5.0 5.7
Power input (4) kW 2.00 1.90
EER (Cooling) or COP(Heating) (4) W/W 2.38 3.16
Energy efficiency class 2.50 3.00
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 9.0 8.5
Starting current A
Circuit breaker rating (IDU/ODU) A 6/20
Fan type & quantity Centrifugal x 1
Fan speeds H/M/L RPM 820/720/620
Air flow (1) H/M/L m3/hr 550/490/420
External static pressure Min-Max Pa 0
Sound power level (2) H/M/L dB(A) 57/55/53
Sound pressure level(3) H/M/L dB(A) 47/45/43
Moisture removal l/hr 1.9
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 600×230×600
Weight kg 20
Package dimensions WxHxD mm 848×310×678
Packaged weight kg 27
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 900
Air flow H/L m3/hr 2800
Sound power level H/L dB(A) 66
Sound pressure level(3) H/L dB(A) 56
Dimensions WxHxD mm 848x540x320
Weight kg 40
Package dimensions WxHxD mm 878x590x360
Packaged weight kg 45
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 1.5/5
Additional charge per 1 meter g/m 30g/m
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 1/2"(12.7)
Max.tubing length m. Max.20
OUTDOOR
Connections between units
Max.height m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
