Airwell DAF009 - 2.19 CAF024; YIF024 Product Data

PRODUCT DATASHEET
SM YIF 2-A.1 GB 2-19
2.19 CAF024 / YIF024
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit CAF024
Model Outdoor Unit YIF024
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Btu/hr 23200 25590
Capacity (4)
kW 6.8 7.5
Power input (4) kW 2.62 2.50
EER (Cooling) or COP(Heating) (4) W/W 2.63 3.18
Energy efficiency class
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 11.7 11.2
Starting current A
Circuit breaker rating (IDU/ODU) A 6/25
Fan type & quantity Centrifugal x 1
Fan speeds H/M/L RPM 600/550/500
Air flow (1) H/M/L m3/hr 1180/1080/1000
External static pressure Min-Max Pa 0
Sound power level (2) H/M/L dB(A) 57/55/53
Sound pressure level(3) H/M/L dB(A) 47/45/43
Moisture removal l/hr 2.35
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 840×260×840
Weight kg 30
Package dimensions WxHxD mm 960×310×960
Packaged weight kg 38
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 940
Air flow H/L m3/hr 3200
Sound power level H/L dB(A) 69
Sound pressure level(3) H/L dB(A) 59
Dimensions WxHxD mm 1018x700x412
Weight kg 59
Package dimensions WxHxD mm 1100x755x450
Packaged weight kg 64
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 2.2/5
Additional charge per 1 meter g/m 60g/m
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 5/8"(15.88)
Max.tubing length m. Max.30
OUTDOOR
Connections between units
Max.height m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
