Airwell DAF009 - 2.20 CAF030; YIF030 Product Data

PRODUCT DATASHEET
2-20 SM YIF 2-A.1 GB
2.20 CAF030 / YIF030
R410
A
PRELIMINARY PRODUCT DATA SHEET
Model Indoor Unit CAF030
Model Outdoor Unit YIF030
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Btu/hr 28320 30030
Capacity (4)
kW 8.3 8.8
Power input (4) kW 2.90 3..15
EER (Cooling) or COP(Heating) (4) W/W 2.86 2.79
Energy efficiency class
Power supply V/Ph/Hz 220-240V/Single/50Hz
Rated current A 13.0 14.1
Starting current A
Circuit breaker rating (IDU/ODU) A 6/30
Fan type & quantity Centrifugal x 1
Fan speeds H/M/L RPM 670/620/570
Air flow (1) H/M/L m3/hr 1400/1270/1170
External static pressure Min-Max Pa 0
Sound power level (2) H/M/L dB(A) 61/59/58
Sound pressure level(3) H/M/L dB(A) 51/49/48
Moisture removal l/hr 2.7
Condenstate drain tube I.D mm 20
Dimensions WxHxD mm 840×260×840
Weight kg 27
Package dimensions WxHxD mm 960×310×960
Packaged weight kg 36
Units per pallet units
INDOOR
Stacking height units
Refrigerant control Capillary
Compressor type, model Rotary
Fan type & quantity Propeller(direct) x 1
Fan speeds H/L RPM 780
Air flow H/L m3/hr 4200
Sound power level H/L dB(A) 69
Sound pressure level(3) H/L dB(A) 59
Dimensions WxHxD mm 980x790x427
Weight kg 70
Package dimensions WxHxD mm 1080x840x485
Packaged weight kg 75
Units per pallet Units
Stacking height units
Refrigerant type R410A
Refrigerant chargeless distance kg/m 3.6/5
Additional charge per 1 meter g/m 60g/m
Liquid line In.(mm) 3/8"(9.53)
Suction line In.(mm) 5/8"(15.88)
Max.tubing length m. Max.30
OUTDOOR
Connections between units
Max.height difference m. Max.15
Operation control type Remote control
Heating elements (Option) kW
Others
(
1
)
Airflow in ducted units
;
at nominal external static
p
ressure.
(2)Sound power in ducted units is measured at air discharge.
(3)Sound pressure level measured at 1-meter distance from unit.
(4)Rating conditions in accordance to ISO 5151 and ISO 13253 (for ducted units).
