OUTLINE DIMENSION
4.3 Indoor Units: CAF012, CAF018, CAF024, CAF036, CAF042
Unit: mm
Model H A B C D
E
CAF012
CAF018
245 650 400 606 440 66
CAF024
CAF030
275 950 680 840 720 76
CAF036
CAF042
345 950 680 840 720 76
SM YIF 2-A.1 GB
4-3
