OUTLINE DIMENSION
4.2 Indoor Units: FAF012, FAF018, FAF024, FAF036, FAF042
Unit: mm
Model A B C D E
FAF012/018
836 238 745 695 260
FAF024/030
1300 188 1202 600 260
FAF036/042
1590 238 1491 695 260
4-2 SM YIF 2-A.1 GB
