PERFORMANCE DATA & PRESSURE CURVES
LEGEND
TC – Total Cooling Capacity, kW
SC – Sensible Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.4.2 Heating Capacity (kW)
ENTERING AIR DB ID COIL(
O
c)
15 20 25
ENTERING WB
OD COIL(
o
C)
TH Pl TH Pl TH Pl
-10 4.20 2.01 4.04 2.14 3.88 2.25
-7 4.52 2.06 4.36 2.17 4.20 2.29
-2 4.80 2.08 4.64 2.21 4.48 2.33
2 5.84 2.18 5.60 2.32 5.36 2.46
6 8.24 2.35
8.00 2.51
7.72 2.67
10 8.96 2.48 8.72 2.65 8.48 2.83
15 9.68 2.59 9.44 2.79 9.20 2.96
20 10.20 2.66 9.96 2.89 9.68 3.11
LEGEND
TH – Total Heating Capacity, kW
PI – Power Input, kW
WB – Wet Bulb Temp., (
o
C)
DB – Dry Bulb Temp., (
o
C)
ID – Indoor
OU – Outdoor
5.4.3 Curves
Cooling
SM YIF 2-A.1 GB 5-9
